Cute Box

CuteBox-4800/4850

https://www.minimallstorage.com/

CuteBox-4850
CuteBox-4800

Feature:

VIA Esther 1.2GHz
512MB DDR2
MPEG4/WMV9 decoding accelerator
TV / S-Video out
2 x USB 2.0 ports
2 x RS-232 ports
Support 2.5″ HDD
PXE diskless boot

Specification
Model No.	cuteBox4800/4850
CPU	VIA Esther 1.2GHz
BIOS	AMI BIOS
System Chipset	onboard 512MB DDR2

I/O
MIO	1x EIDE, 1x PS/2 K/B, 1x PS/2 Mouse
USB	2x USB 2.0 Ports (one on front)

Display
Chipset	Integrated VIA UniChrome 2D/3D Graphics with MPEG4/WMV9 decoding accelerator
Display Memory	up to 64 MB share system memory
Resolution	up to 1920×1440

Audio
AC97 2.2 (Codec)	VIA Vinyl VT1708
Audio Interface	Line out, Mic in

Ethernet
Chipset	Realtek 8100B 10/100 Base-T
Remote Boot ROM	built-in boot ROM function, support PXE boot and Wake-up on LAN

Mechanical & Environment
Power Requirement	+5V @4.0A
Operating Temperature	0 ~ 60oC
Operating Humidity	0%-90% relative humidity, non-condensing
Size (WxHxD)	170x123x38mm(cuteBox-4800) 170x123x56mm (cuteBox-4850)
Weight	789g (cuteBox-3800) 970g (cuteBox-3850)
Certification	CE, FCC
Note: * Specifications is subject to change without prior notice Order information: cuteBox-4800 (512MB): VGA out cuteBox-4810 (1GB) : VGA out cuteBox-4800T (512MB): TV out cuteBox-4810T (1GB) : TV out cuteBox-4850 (512MB): VGA out, with support for 2.5″ HDD cuteBox-4860 (1GB) : VGA out, with support for 2.5″ HDD cuteBox-4850T (512MB): TV out, with support for 2.5″ HDD cuteBox-4860T (1GB): TV out, with support for 2.5″ HDDManual Download

Products (4)

CuteBox-3800SL

Feature:

VIA Eden Nano 800Mhz (Fanless)
256MB DDR2 onboard
10/100Mbps LAN
PXE diskless boot
2 x USB 2.0 ports (one at front)

Specification
Model No.	CuteBox-3800SL
CPU	VIA EDEN-N Nano processor
BIOS	AMI BIOS
System Chipset	VIA CLE266 / VT8235
I/O Chip	VIA VT1211
System Memory	256MB DDR2 onboard
Expansion	1 x X-PCI connector
MIO	1 x PS/2 K/B, 1 x PS/2 Mouse
USB	2 x USB 2.0 Ports (one at front)
Chipset	Integrated VIA UniChrome 2D/3D Graphics with MPEG2 Accelerator
Display Memory	8/16/32/64MB share system memory
Resolution	Up to 1280 x 1024
AC97 2.2 (Codec)	VIA VT1612A
Audio Interface	Line out, Mic in
Chipset	VIA VT6103 10/100 Base-T Ethernet PHY
Remote Boot ROM	built-in boot ROM function
Power Requirement	+5V @ 4.5A
Operating Temperature	0 ~ 60 C (32 – 140F)
Operating Humidity	0% – 90% relative humidity, non-condensing
Size (W x H x D)	175 x 128 x 46mm
Weight	780g
Certification	CE, FCC, VCCI
Note: * Specifications is subject to change without prior notice

Products (4)

CuteBox-2300SX

Feature:

Support VESA mounting holes
128MB DDR2 onboard
Fanless design
24-bit GPIO
2xRS-232
3xUSB2.0 ports (two at front)
Mini PCI socket
Compact Flash Slot
Support Wireless LAN (Option)

Specification
Model No.	CuteBox-2300SX
CPU	Vortex86SX SoC
BIOS	AMI BIOS
System Memory	onboard 128MB DDR2
Expansion	1x Mini-PCI connector (option for cute-box-2300SX-M)
I/O
MIO	1 x EIDE (44-pin) 2 x RS-232**,, 1x PS/2 for K/B or Mouse 1 x RJ-45 Ethernet Connector 1 x Type I/II Compact Flash slot
USB	3 x USB 2.0 Ports (two in front)
Display
VGA	XGI Z9S with 32MB DDR2 External 15-pin D-type female VGA connector
Resolution	Up to 1280×1024
Ethernet
Remote Boot ROM	Built-in boot ROM function
Mechanical & Environment
Power Requirement	5V @ 1080mA
Operating Temperature	0 ~ 60oC
Operating Humidity	0% – 90% relative humidity, non-condensing
Size (WxHxD)	115 x 115 x 35 mm
Weight	505g
Certification	CE,FCC
Ordering Information: cuteBox-2300SX : Standard version cuteBox-2300SX-H : Standard version with support for 2.5″ HDD cuteBox-2300SX-M : Standard version with Mini PCI socket cuteBox-2300SX-JSK : Standard version with Mini PCI socket, 2 X RS-232 and 24-bit GPIO cuteBox-2300SX-LS : Thin client edition with RDP, ICA, VNC and XDMCP protocol. cuteBox-2300SX-NWP : The Network Projector Access Point Note: * Specifications is subject to change without prior notice

Products (4)

CuteBox-2300

Feature:

Support VESA mounting holes
Compact Flash Slot
On-Board 10/100Mbps LAN
Ultra low power (15 Watts)
PXE diskless boot
2.5″ Hard Disk installation
Wireless LAN (optional)
2 x RS-232 (optional)

Specification
Model No.	CuteBox-2300
CPU	Vortex86-200Mhz (SoC: System-on-Chip) (Fanless)
BIOS	AMI BIOS
System Memory	128MB SDRAM onboard
Flash Memory	Support 32MB up to 2GB Horizontal type Disk On Module
VGA	Shared System Memory Area 8MB External 15-pin D-type female VGA connector
I/O	Enhanced IDE interface, 44-pin box header x 1 Type I/II Compact Flash Slot x 1 Mini PCI Socket x 1 (Optional) RS-232 Port x 2 (Optional) RJ-45 Ethernet Connector USB 1.1 port x 3 External 6 -pin Mini DIN for PS2 keyboard External 6 -pin Mini DIN for PS2 Mouse
Audio	AC97, CODEC, Fully Compliant with AC97 V2.1 Phone jack for Line-out, Mic-in
Power Requirement	Single Voltage +5V @3A , w/ ACPI function support
Operating Temperature	0 ~ +60 C (32 – 140F)
Operating Humidity	0% – 90% relative humidity, non-condensing
Size (W x H x D)	120 x 120 x 40mm
Weight	505g
Certification	CE, FCC
Note: * Specifications is subject to change without prior notice
